Radiator Filler Neck Inspection


Radiator Cap Inspection
Remove: Radiator Cap (see Coolant Change in the Periodic Maintenance chapter) Check the condition of the bottom [A] and top [B] valve seals and valve spring [C]. If any one of them shows ...

Thermostat
...

Other materials:

Connecting Rod Big End Bearing Insert/Crankpin Wear Inspection
Remove the connecting rod big end (see Connecting Rod Removal). Cut strips of plastigage to crankpin width. Place a strip on the crankpin parallel to the crankshaft installed in the correct position. Tighten the connecting rod big end nuts to the specified torque (see Connecting Rod I ...

DFI System Wiring Diagram (KIBS Equipped Models)
1. Air Intake Solenoid Valve (Other than US, CA and CAL Models) 2. Engine Stop Switch 3. Starter Button 4. Air Switching Valve 5. Stick Coil #1, #2, #3, #4 6. Spark Plugs 7. Intake Air Temperature Sensor 8. Crankshaft Sensor 9. Secondary Fuel Injector #1 10. Secondary Fuel Injector #2 ...

Connecting Rod Big End Side Clearance Inspection
Measure connecting rod big end side clearance. Insert a thickness gauge [A] between the big end and either crank web to determine clearance. Connecting Rod Big End Side Clearance Standard: 0.13 0.38 mm (0.0051 0.0150 in.) Service Limit: 0.58 mm (0.023 in.) If the clearance exceeds ...
