Kawasaki Ninja Service Manual: Air Cleaner Element Inspection - Air Cleaner

Air Cleaner Oil Draining

A drain hose is connected to the bottom of the air cleaner to drain water or oil accumulated in the cleaner part. Visually check the drain hose [A] if the water or oil accumulates. If any wate ...

Other materials:

Front Wheel Rotation Sensor Wiring Inspection (Service Code b 43)
Disconnect the front wheel rotation sensor lead connector [A] (see Front Wheel Rotation Sensor Removal in the Brakes chapter). Disconnect the KIBS hydraulic unit lead connector (see KIBS Hydraulic Unit Removal in the Brakes chapter). Check the wiring continuity of the W lead and ...

Terminal Numbers of ECU Connectors
1. Subthrottle Valve Actuator: Y/BK 2. Subthrottle Valve Actuator: BK/O 3. Unused 4. Front Wheel Rotation Sensor Signal: G/Y 5. Unused 6. Starter Lockout Switch: R/G 7. Gear Position Switch: G/R 8. Crankshaft Sensor (–): BK 9. Power Supply to Sensors: BL 10. Unused 11. Intake Air Pre ...

Connecting Rod Twist Inspection
With the big-end arbor [A] still on V block [C], hold the connecting rod horizontally and measure the amount that the arbor [B] varies from being paralleled with the surface plate over a 100 mm (3.94 in.) length of the arbor to determine the amount of connecting rod twist. If the conne ...
